PROCTOR Spacetherm® Cold Bridge Strip

PROCTOR Spacetherm® Cold Bridge Strip


PROCTOR Spacetherm® Cold Bridge Strip is designed to prevent cold bridging through a component or element of a structure. Spacetherm CBS (Cold Bridge Strip) consists of Spacetherm Aerogel insulation encapsulated in polyethelene. Spacetherm CBS is an ideal choice for timber or steel frame structures and on request, can be cut to a variety of widths to suit different applications. In addition to timber and steel structures, it can also be used in other applications where cold bridging is an issue.

Read more Read less
Quantity

Key points
  • Thin thermal bridge insulation ideal for timber or steel frame structures.
  • Fully encapsulated.
  • Class-leading performance.
  • Fast and easy to fix with adhesive backing.
  • Constant long term thermal performance 50 years +.
  • Available to any width or thickness.
  • Non-hazardous material.

Specification

Length: 1200 or 2400mm
Width: 38, 50, 75 & 100mm
Thickness: 10 or 20mm
Thermal Conductivity: 0.015 W/mK
Reaction to Fire: Class C-s1, d0 (EN 13501-1)

Application

Installation:

Peel off release paper to temporarily adhere to structure where required.

Cutting:

Spacetherm CBS can be cut using scissors or knife. Care should be taken that cutting blades are kept sharp, if using a knife, the angle between the blade and the Spacetherm CBS should be kept as low as possible. It is advisable to re-seal the ends with tape after cutting is complete.



PROCTOR Spacetherm® Cold Bridge Strip
PROCTOR Spacetherm® Cold Bridge Strip

Width: 38mm

Stirling Shop

Unit 3, 24 Munro Road
Springkerse Industrial Estate
Stirling FK7 7UU
United Kingdom

Pickup available, usually ready in 24 hours

PROCTOR Spacetherm® Cold Bridge Strip

Best Seller

PROCTOR Spacetherm® Silica Aerogel Blanket

Aerogel is a synthetic porous ultralight gel-like material created by removing the liquid component from gel and replacing it with gas, without any degradation to the gel structure. This produces an extremely low thermal conductivity which is perfect for thermal insulation.
